Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance
  • Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance
  • Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance
  • Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance
  • Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance

Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance

Место происхождения Китай
Фирменное наименование TBC LED
Сертификация FCC, CE, ROHS
Номер модели P8.33
Детали продукта
тип:
На открытом воздухе периметр СИД футбольного стадиона
Шаг пикселя:
P8.33 мм
Размер шкафа:
1600х900 мм
Служба:
Передняя и задняя служба
Масса:
45 кг
Тип светодиода:
Высокая яркость SMD3727
Угол обзора:
H160°/V160°
Максимальная потребляемая мощность (Вт/㎡):
600-800
Гарантия:
3 года
Условия оплаты и доставки
Количество мин заказа
10 кв.м.
Цена
Подлежит обсуждению
Упаковывая детали
Случаи полета
Время доставки
25 дней
Условия оплаты
Т/Т
Поставка способности
1000 кв.м в месяц
Характер продукции
Outdoor P8.33 Perimeter LED Display IP65 Front Rear Maintenance Stadium Screen
Outdoor P8.33mm LED Perimeter Folding Aluminum Bracket 7000nits High Brightness 3840Hz Refresh Rate
Product Specifications
ParameterSpecification
ModelP8.33mm
LEDs1R1G1B
LED TypeSMD2727
Pixel Pitch8.33mm
Unit SizeW1600*H900mm
Unit Resolution192*108 dots
Resolution14,400 dots/㎡
Unit DirectionVertical Horizontal
Brightness7000nit
Weight45KG/Panel
Max Consumption600-800W/㎡
Average Consumption100-200W/㎡
Viewing AngleH160°/V160°
Protection LevelIP65
Thickness98mm
Heat DissipationConvective heat dissipation
Power SupplyPower supply with PFC
InstallationFast install
ServiceFront & Back
Control ModeSteady state
Color Temperature3200-9300K
Refresh Rate3840Hz
Working Temperature-40℃ to 70℃
Storage Temperature-55℃ to 120℃
Life Time≥100,000 hours
Input VoltageAC90-264V
Grey Grade16bit
Warranty3 years
Key Features
  • Polymer soft mask for better contrast and player protection
  • High-quality aluminum cabinet - only 45kg per panel
  • Ultra-thin design - just 98mm thickness
  • IP65 protection rating on both front and rear sides
  • 160° super wide viewing angle
  • 7000cd/㎡ brightness with 5000:1 contrast ratio
  • 16-bit gray scale processing technology
  • Adjustable folding brackets with multiple angle options
  • Full front and rear maintenance access
  • Seamless splicing with perfect flatness
Product Images
Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance 0 Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance 1 Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance 2 Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance 3 Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance 4 Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance 5 Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance 6 Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance 7 Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance 8 Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance 9 Outdoor P8.33 Perimeter LED Display with 7000nits High Brightness 3840Hz Refresh Rate and Front & Rear Maintenance 10
Our Services
  • 10 Years professional LED display manufacturing experience
  • Short delivery time: 5-15 working days
  • Competitive wholesale pricing
  • OEM and ODM services available
  • Customizable products upon request
Frequently Asked Questions
How does the service work?
We have experienced engineers with 15+ years in the industry who provide technical support via video conference, TeamViewer, or on-site guidance.
What installation options do we have?
Wall mounting with metal structures.
Do you have any MOQ limit for LED screen orders?
Low minimum order quantity - modules or complete screen orders are all welcome.
What's the shipping method?
Air freight, sea, and train transport available depending on region.
What's the payment method?
Telegraphic transfer - 50% before production and 50% balance before shipment.
How do you control the production quality?
Quality management from incoming materials, pre-inspected components, and 72+ hours aging tests for modules and complete screens.
How does warranty work?
1-3 years warranty with free repair or exchange of defective parts including one-way shipping.
